| Onderdeel nommer | LC550EQP-SPA1 |
| Handelsmerk | LG Display |
| Grootte | 55 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 1300:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | EPI |
| vervaardiger | LG Display |
| model naam | LC550EQP-SPA1 |
| skerm grootte | 55 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 3840(RGB)×2160 (UHD) 80PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 1209.6 × 680.4 (H×V) |
| buitelyn (mm) | 1221.4 × 694.8 × 1.2 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare (Haze 3%), Hard coating (2H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 1300 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 8/10 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| glas dikte | - |
| deurlaatbaarheid | 5.77% (Typ.) |
| kleurdiepte | 1.07B 68% NTSC |
| agterlig | No B/L |
| massa | 2.5/2.63Kgs (Typ./Max.) |
| gebruik vir | TV Sets |
| herlaaitempo | 120Hz |
| raakskerm | Without |
| sein tipe | EPI , Connector 136 pins |
| spanningstoevoer | 12.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
