| Onderdeel nommer | LC550EQH-DJF1 |
| Handelsmerk | LG Display |
| Grootte | 55 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleure | 1.06B |
| Agterlig | WLED |
| Koppelvlak | EPI |
| handelsmerk | LG Display |
| model | LC550EQH-DJF1 |
| diagonale grootte | 55 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 3840(RGB)×2160 [UHD] 80PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 1209.6(H)×680.4(V) mm |
| buitelyn dof. | 1239.8(H)×716.3(V) ×27.8(D) mm |
| ring area | - |
| behandeling | Antiglare (Haze 3%), Hard coating (2H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1400:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 8/10 (Typ.)(Tr/Td) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 1.06B 82% NTSC |
| Ligbron | WLED , 30K hours , W/O Driver |
| gewig | 13.7/14.4Kgs (Typ./Max.) |
| ontwerp vir | TV Sets |
| raamkoers | 120Hz |
| raakpaneel | Without |
| koppelvlak tipe | EPI , 160 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| LC550EGE-FHM1 | LG Display | 55 | 3840×2160 |
| LC550EUD-FFF1 | LG Display | 55 | 1920×1080 |
| LC550EUE-SEM1 | LG Display | 55 | 1920×1080 |
| LC550EUE-SER1 | LG Display | 55 | 1920×1080 |
| LC550EUG-PFF1 | LG Display | 55 | 1920×1080 |
| LC550EUH-LFF1 | LG Display | 55 | 1920×1080 |
| LC550EUJ-FFK1 | LG Display | 55 | 1920×1080 |
| LC550EUJ-SFK2 | LG Display | 55 | 1920×1080 |
| LC550EUN-SEF1 | LG Display | 55 | 1920×1080 |
| LC550EUN-SFF1 | LG Display | 55 | 1920×1080 |
