| Onderdeel nommer | LC550EQF-YJF1 |
| Handelsmerk | LG Display |
| Grootte | 55 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1400:1 |
| Kleure | 16.7M/1.06B |
| Agterlig | WLED |
| Koppelvlak | V-by-One |
| paneel handelsmerk | LG Display |
| paneel model | LC550EQF-YJF1 |
| paneel grootte | 55" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 3840(RGB)×2160, UHD, 80PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 1209.6(W)×680.4(H) mm |
| ring opening | - |
| omtrek grootte | 1232.2(W)×708.6(H) ×50.1(D) mm |
| oppervlak | Antiglare (Haze 3%), Hard coating (2H) |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 1400:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 5 (Typ.)(G to G); 8 (Typ.)(MPRT) |
| kleure vertoon | 16.7M/1.06B 87% NTSC |
| tipe lamp | WLED , 30K hours , Without Driver |
| frekwensie | 120Hz |
| raakskerm | Without |
| paneel gewig | 12.5/13.2Kgs (Typ.) |
| aansoek | TV Sets |
| sein koppelvlak | V-by-One 16 lane , 97 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
