| Onderdeel nommer | LC490DUE-FJM1 |
| Handelsmerk | LG Display |
| Grootte | 49 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | LG Display |
| paneel grootte | 49" |
| resolusie | 1920(RGB)×1080, FHD, 45PPI |
| vertoon area | 1073.8(W)×604(H) mm |
| omtrek grootte | 1106.8(W)×640.6(H) mm |
| helderheid | 300 cd/m² (Min.) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 68% NTSC |
| frekwensie | 60Hz |
| paneel gewig | - |
| sein koppelvlak | LVDS (2 ch, 8-bit) , 51 pins Connector |
| insetspanning | 12.7V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | LC490DUE-FJM1 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 1078.3(W)×608.5(H) mm |
| oppervlak | - |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| reaksie tyd | 9 (Typ.)(G to G) |
| tipe lamp | WLED , 50K hours , Without Driver |
| raakskerm | Without |
| aansoek | TV Sets |
