LC470EUD-SCA1

LC470EUD-SCA1
LC470EUD-SCA1
LC470EUD-SCA1 thumb LC470EUD-SCA1 thumb
Handelsmerk
LG Display
Grootte
47
Toepassing
LCTV
Resolusie
1920×1080
Samestelling
LCM
Helderheid
450
CR
1400:1
Kleure
16.7M/1.06B
Agterlig
WLED
Koppelvlak
LVDS
In Stock
2904
Spesifikasies

Onderdeel nommer LC470EUD-SCA1
HandelsmerkLG Display
Grootte47
ToepassingLCTV
Resolusie1920×1080
SamestellingLCM
Helderheid450
CR1400:1
Kleure16.7M/1.06B
AgterligWLED
KoppelvlakLVDS
paneel handelsmerkLG Display
paneel modelLC470EUD-SCA1
paneel tipe a-Si TFT-LCD , LCM
paneel grootte47 inch
resolusie1920(RGB)×1080 , FHD
vertoonmodusS-IPS, Normally Black, Transmissive
aktiewe area1039.68×584.82 mm
buitelyn1083.6×628.8 mm
oppervlakAntiglare (Haze 10%), Hard coating (3H)
helderheid450 cd/m² (Typ.)
kontras verhouding1400:1 (Typ.)
kleure vertoon16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
reaksie tyd5 (Typ.)(G to G); 8 (Typ.)(MPRT)
kykhoek89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekwensie120Hz+120Hz
tipe lampWLEDEmbedded (LED Driver)
sein koppelvlakLVDS (4 ch, 8/10-bit), 92 pins
insetspanning12.0V (Typ.)
aansoekLCTV
