| Onderdeel nommer | LC430DGG-FKM3 |
| Handelsmerk | LG Display |
| Grootte | 43 |
| Toepassing | TV Sets |
| Resolusie | 38403×2160 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 1.07B |
| Agterlig | WLED |
| Koppelvlak | EPI |
| paneel handelsmerk | LG Display |
| paneel model | LC430DGG-FKM3 |
| paneel grootte | 43" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 3840(3)×2160, UHD, 103PPI |
| pixel formaat | RGBW Vertical Stripe |
| vertoon area | 941.184(W)×529.416(H) mm |
| ring opening | 944.2(W)×532.4(H) mm |
| omtrek grootte | 973.57(W)×565.63(H) mm |
| oppervlak | Antiglare (Haze 3%), Hard coating (2H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 8/10 (Typ.)(Tr/Td) |
| kleure vertoon | 1.07B 84% NTSC |
| tipe lamp | WLED , 30K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 6.00/6.60Kgs (Typ./Max.) |
| aansoek | TV Sets |
| sein koppelvlak | EPI , 120 pins Connector |
| insetspanning | 12.7V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
