| Onderdeel nommer | LC320DUE-FKA1 |
| Handelsmerk | LG Display |
| Grootte | 32.0 |
| Toepassing | TV Sets |
| Resolusie | 1920×1080 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | LG Display |
| model naam | LC320DUE-FKA1 |
| skerm grootte | 32.0 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 69PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 698.4 × 392.85 (H×V) |
| buitelyn (mm) | 739 × 436.3 (H×V×D) |
| ring area (mm) | 701.4 × 395.4 (H×V) |
| behandeling | Antiglare (Haze 3%), Hard coating (2H) |
| helderheid | 240 cd/m² (Typ.) |
| kontras verhouding | 1200 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| reaksie | 7 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 70% NTSC |
| agterlig | WLED , 30K hours , No Driver |
| massa | 3.20/3.50Kgs (Typ./Max.) |
| gebruik vir | TV Sets |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (2 ch, 8-bit) , 51 pins Connector |
| spanningstoevoer | 12.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
