| Onderdeel nommer | LB270WR1-SPA1 |
| Handelsmerk | LG Display |
| Grootte | 27.0 |
| Toepassing | Medical Imaging |
| Resolusie | 3840×2160 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 1.07B |
| Agterlig | 18S4P×2CN |
| Koppelvlak | eDP |
| vervaardiger | LG Display |
| model naam | LB270WR1-SPA1 |
| skerm grootte | 27.0 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 3840(RGB)×2160 (UHD) 163PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 596.16 × 335.34 (H×V) |
| buitelyn (mm) | 649.84 × 387.13 × 17.3 (H×V×D) |
| ring area (mm) | - |
| behandeling | Anti Fingerprint, Hard coating, Antireflection |
| helderheid | 800 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 14 (Typ.)(G to G) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 1.07B 100% sRGB |
| agterlig | 18S4P×2CN WLED , 30K hours , No Driver |
| massa | 3.85/4.05Kgs (Typ./Max.) |
| gebruik vir | Medical Imaging |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | eDP (4 Lanes) , HBR2 (5.4G/lane) , 30 pins Connector |
| spanningstoevoer | 10.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
