| Onderdeel nommer | LA123WF4-SR05 |
| Handelsmerk | LG Display |
| Grootte | 12.3 |
| Toepassing | Automotive Display |
| Resolusie | 1920×720 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | 8S6P |
| Koppelvlak | RSDS |
| paneel handelsmerk | LG Display |
| paneel model | LA123WF4-SR05 |
| paneel grootte | 12.3" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1920(RGB)×720, 167PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 292.032(W)×109.512(H) mm |
| ring opening | 296.03(W)×113.5(H) mm |
| omtrek grootte | 310(W)×128(H) ×10.75(D) mm |
| oppervlak | Hard coating |
| helderheid | 420 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Min.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| vertoonmodus | IPS, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| kleure vertoon | 16.7M 77% NTSC |
| tipe lamp | 8S6P WLED , 10K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 395/405g (Typ./Max.) |
| aansoek | Automotive Display |
| sein koppelvlak | RSDS (2 Channel) , 110 pins FPC |
| insetspanning | 3.3/13.0V (Typ.)(VCC/VDD) |
| omgewing | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
