| Onderdeel nommer | LA121WH1-SL02 |
| Handelsmerk | LG Display |
| Grootte | 12.1 |
| Toepassing | Automotive Display |
| Resolusie | 1280×720 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 8S3P |
| Koppelvlak | LVDS |
| vervaardiger | LG Display |
| model naam | LA121WH1-SL02 |
| skerm grootte | 12.1 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×720 (WXGA) 121PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 266.88 × 150.12 (H×V) |
| buitelyn (mm) | 287.4 × 163.45 × 9.51 (H×V×D) |
| ring area (mm) | 269.65 × 152.55 (H×V) |
| behandeling | Antiglare |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Min.)(CR≥10) |
| reaksie | 17/13 (Max.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 62% NTSC |
| agterlig | 8S3P WLED , 10K hours , No Driver |
| massa | 417±5g |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 8-bit) , 40 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
