| Onderdeel nommer | LA102WH2-SL01 |
| Handelsmerk | LG Display |
| Grootte | 10.2 |
| Toepassing | Automotive Display |
| Resolusie | 1280×720 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | 10S4P |
| Koppelvlak | LVDS |
| vervaardiger | LG Display |
| model naam | LA102WH2-SL01 |
| skerm grootte | 10.2 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×720 (WXGA) 143PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 225.792 × 127.008 (H×V) |
| buitelyn (mm) | 238.62 × 141.5 (H×V×D) |
| ring area (mm) | 225.75 × 126.874 (H×V) |
| behandeling | Hard coating (3H) |
| helderheid | 725 cd/m² (Min.) |
| kontras verhouding | 800 : 1 (Min.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| reaksie | 30 (Max.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.7M |
| agterlig | 10S4P WLED , 10K hours , No Driver |
| massa | 303/313g (Typ./Max.) |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 8-bit) , FPC 64 pins |
| spanningstoevoer | 1.8/3.3/12.5/18.5/-7.5V (Typ.)(DVDD2/DVDD1/AVDD/VHG/VHL) |
| maks. graderings | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.16G (31.0 m/s²) |
