| Onderdeel nommer | LA090WH1-SL01 |
| Handelsmerk | LG Display |
| Grootte | 9.0 |
| Toepassing | Automotive Display |
| Resolusie | 1280×720 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | LG Display |
| model | LA090WH1-SL01 |
| diagonale grootte | 9.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×720 [WXGA] 164PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 200.448(H)×106.056(V) mm |
| buitelyn dof. | 213.2(H)×121.2(V) ×8.6(D) mm |
| ring area | 203.148(H)×108.756(V) mm |
| behandeling | Antiglare |
| helderheid | 600 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 17/13 (Max.)(Tr/Td) |
| kykhoek | 80/80/80/80 (Min.)(CR≥10) |
| bedryfsmodus | IPS, Normally Black, Transmissive |
| ondersteun kleur | 16.7M 65% NTSC |
| Ligbron | WLED [6S3P] , 10K hours , W/O Driver |
| gewig | 219/224g (Typ./Max.) |
| ontwerp vir | Automotive Display |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 8-bit) , 60 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AT090TN10 | Innolux | 9.0 | 800×480 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| G090VTN02.0 | AUO | 9.0 | 800×480 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| LTL090CL01-W02 | Samsung | 9.0 | 1920×1280 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
