| Onderdeel nommer | LA084X02-SL01 |
| Handelsmerk | LG Display |
| Grootte | 8.4 |
| Toepassing | Automotive Display |
| Resolusie | 1024×768 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.2M |
| Agterlig | 10S3P |
| Koppelvlak | LVDS |
| vervaardiger | LG Display |
| model naam | LA084X02-SL01 |
| skerm grootte | 8.4 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×768 (XGA) 152PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 170.496 × 127.872 (H×V) |
| buitelyn (mm) | 184.5 × 143 × 9.95 (H×V×D) |
| helderheid | 1200 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Min.)(CR≥10) |
| reaksie | 40 (Max.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS, Normally Black, Transmissive |
| kleurdiepte | 16.2M 70% NTSC |
| agterlig | 10S3P WLED , No Driver |
| massa | 255/260g (Typ./Max.) |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 8-bit) , FPC 40 pins |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.84G (27.8 m/s²) |
