| Onderdeel nommer | LA058WQ1-SD01 |
| Handelsmerk | LG Display |
| Grootte | 5.8 |
| Toepassing | CNS |
| Resolusie | 400×240 |
| Samestelling | LCM |
| Helderheid | |
| CR | |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | TTL |
| paneel handelsmerk | LG Display |
| paneel model | LA058WQ1-SD01 |
| paneel tipe | a-Si TFT-LCD , LCM |
| paneel grootte | 5.8 inch |
| resolusie | 400(RGB)×240 , WQVGA |
| vertoonmodus | IPS, Normally Black, Transmissive |
| aktiewe area | 126.36×75.84 mm |
| buitelyn | 152×97 mm |
| oppervlak | Antiglare, Antireflection |
| helderheid | |
| kontras verhouding | |
| kleure vertoon | 262K (6-bit) |
| reaksie tyd | |
| kykhoek | |
| frekwensie | 60Hz |
| tipe lamp | WLED |
| sein koppelvlak | Parallel RGB (1 ch, 6-bit) |
| insetspanning | 3.3V (Typ.) |
| aansoek | CNS |
