| Onderdeel nommer | KHS072VG1MB-G40 |
| Handelsmerk | Kyocera |
| Grootte | 7.2 |
| Toepassing | Industrial |
| Resolusie | 640×480 |
| Samestelling | CSTN-LCD, LCM |
| Helderheid | |
| CR | 5:1 |
| Kleure | Color |
| Agterlig | CCFL |
| Koppelvlak | |
| handelsmerk | Kyocera |
| model | KHS072VG1MB-G40 |
| diagonale grootte | 7.2 inch |
| tipe | CSTN-LCD, LCM |
| pixel formaat | 640(RGB)×480 [VGA] 111PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 145.9(H)×109.42(V) mm |
| buitelyn dof. | 179.3(H)×130.5(V) ×6.5(D) mm |
| ring area | 147.9(H)×111.42(V) mm |
| behandeling | - |
| helderheid | - |
| kontras verhouding | 5:1 (Typ.) (RF) |
| kyk rigting | - |
| reaksie tyd | 200/150 (Typ.)(Tr/Td) |
| kykhoek | 50/50/40/30 (Typ.)(CR≥2) |
| bedryfsmodus | STN, Normally Black, Transflective |
| ondersteun kleur | Color |
| Ligbron | CCFL [1 pcs] , 40K hours , Optional |
| gewig | - |
| ontwerp vir | Industrial |
| raamkoers | 75Hz |
| raakpaneel | Without |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
