| Onderdeel nommer | KHS038AA1AG-G83 |
| Handelsmerk | Kyocera |
| Grootte | 3.8 |
| Toepassing | Industrial |
| Resolusie | 240×320 |
| Samestelling | LCM , CSTN-LCD |
| Helderheid | |
| CR | 15:1 |
| Kleure | Color |
| Agterlig | 1 |
| Koppelvlak | Parallel |
| vervaardiger | Kyocera |
| skerm grootte | 3.8 inch |
| pixel nommer | 240(RGB)×320 (QVGA) 105PPI |
| aktiewe area (mm) | 57.58 × 76.78 (H×V) |
| helderheid | 16 cd/m² (Typ.) |
| kykhoek | 50/45/20/30 (Typ.)(CR≥2) |
| goeie uitsig by | - |
| kleurdiepte | Color |
| massa | - |
| herlaaitempo | 75Hz |
| sein tipe | Parallel Data (1ch, 8-bit) FPC |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model naam | KHS038AA1AG-G83 |
| tipe skerm | LCM , CSTN-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | - |
| kontras verhouding | 15 : 1 (Typ.) (TM) |
| reaksie | 250/150 (Typ.)(Tr/Td) ms |
| werksmodus | STN, Normally Black, Transflective |
| agterlig | 1 pcs CCFL , No Driver |
| gebruik vir | Industrial |
| raakskerm | - |
