| Onderdeel nommer | JJ070IA-18L |
| Handelsmerk | Innolux |
| Grootte | 7.0 |
| Toepassing | Automotive Display |
| Resolusie | 800×480 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 7S2P |
| Koppelvlak | LVDS |
| vervaardiger | Innolux |
| skerm grootte | 7.0 inch |
| pixel nommer | 800(RGB)×480 (WVGA) 133PPI |
| aktiewe area (mm) | 152.4 × 91.44 (H×V) |
| ring area (mm) | 155.4 × 94.44 (H×V) |
| helderheid | 750 cd/m² (Typ.) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 70% NTSC |
| massa | 195±9g |
| herlaaitempo | 60Hz |
| sein tipe | LVDS (1 ch, 8-bit) , 50 pins FPC |
| spanningstoevoer | 3.3/13.3/26/-7V (Typ.)(VDD/VDDA/VGH/VGL) |
| maks. graderings | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| model naam | JJ070IA-18L |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 162.8 × 104.84 (H×V×D) |
| behandeling | Antiglare |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| reaksie | 15/10 (Typ.)(Tr/Td) ms |
| werksmodus | IPS, Normally Black, Transmissive |
| agterlig | 7S2P WLED , 20K hours , No Driver |
| gebruik vir | Automotive Display |
| raakskerm | Without |
