| Onderdeel nommer | JJ068IA-07B |
| Handelsmerk | Innolux |
| Grootte | 6.8 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 1280×720 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 900:1 |
| Kleure | 16.7M |
| Agterlig | 6S3P |
| Koppelvlak | |
| vervaardiger | Innolux |
| model naam | JJ068IA-07B |
| skerm grootte | 6.8 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×720 (WXGA) 217PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 152.064 × 79.603 (H×V) |
| buitelyn (mm) | 167 × 93 × 9.75 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare |
| helderheid | 750 cd/m² (Typ.) |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 15/10 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AAS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 70% NTSC |
| agterlig | 6S3P WLED , 20K hours , No Driver |
| massa | 185g (Typ.) |
| gebruik vir | Outdoor High Brightness Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
