| Onderdeel nommer | HV650QUB-F9A |
| Handelsmerk | BOE |
| Grootte | 65 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | V-by-One |
| handelsmerk | BOE |
| model | HV650QUB-F9A |
| diagonale grootte | 65 inch |
| tipe | a-Si TFT-LCD, CELL |
| pixel formaat | 3840(RGB)×2160 [UHD] 68PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 1428.48(H)×803.52(V) mm |
| buitelyn dof. | 1438.48(H)×815.02(V) mm |
| ring area | - |
| behandeling | Antiglare (Haze 1%) |
| helderheid | 0 cd/m² |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 8 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| plaat dikte | 0.50+0.50 mm |
| oordrag | 5.1% (Typ.)(with Polarizer) |
| ondersteun kleur | 1.07B 99% sRGB |
| Ligbron | No B/L |
| gewig | TBD |
| ontwerp vir | TV Sets |
| raamkoers | 60Hz |
| raakpaneel | Without |
| d-ic detail | COF Built-in 12 source chips |
| koppelvlak tipe | V-by-One 8 lane , 51 pins Connector |
| kragtoevoer | 12.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
