| Onderdeel nommer | HV550WU2-370 |
| Handelsmerk | BOE |
| Grootte | 55 |
| Toepassing | LCTV |
| Resolusie | 1920×1080 |
| Samestelling | CELL |
| Helderheid | 0 |
| CR | 1200:1 |
| Kleure | 16.7M |
| Agterlig | No B/L |
| Koppelvlak | LVDS |
| paneel handelsmerk | BOE |
| paneel model | HV550WU2-370 |
| paneel tipe | a-Si TFT-LCD , CELL |
| paneel grootte | 55 inch |
| resolusie | 1920(RGB)×1080 , FHD |
| vertoonmodus | ADS, Normally Black, Transmissive |
| aktiewe area | 1209.6×680.4 mm |
| buitelyn | 1224.8×699.3 mm |
| oppervlak | Antiglare (Haze 1%), Hard coating (2H) |
| glas diepte | 0.70+0.70 mm |
| deurlaatbaarheid | 6.3% (Typ.)(with Polarizer) |
| kontras verhouding | 1200:1 (Typ.) |
| kleure vertoon | 16.7M (8-bit) |
| reaksie tyd | 8 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| sein koppelvlak | LVDS (2 ch, 8-bit), 51 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | LCTV |
