| Onderdeel nommer | HV550QUB-V10 |
| Handelsmerk | BOE |
| Grootte | 55 |
| Toepassing | TV Sets |
| Resolusie | 3840×2160 |
| Samestelling | a-Si TFT-LCD, CELL |
| Helderheid | |
| CR | 1200:1 |
| Kleure | 1.07B |
| Agterlig | No |
| Koppelvlak | |
| handelsmerk | BOE |
| model | HV550QUB-V10 |
| diagonale grootte | 55 inch |
| tipe | a-Si TFT-LCD, CELL |
| pixel formaat | 3840(RGB)×2160 [UHD] 80PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 1209.6(H)×680.4(V) mm |
| buitelyn dof. | 1221.4(H)×694.8(V) ×1.34(D) mm |
| ring area | - |
| behandeling | Antiglare (Haze 1%), Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 1200:1 (Typ.) (TM) |
| kyk rigting | Symmetry |
| reaksie tyd | 8 (Typ.)(G to G) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| bedryfsmodus | ADS, Normally Black, Transmissive |
| plaat dikte | 0.50+0.50 mm |
| oordrag | 5.4% (Typ.)(with Polarizer) |
| ondersteun kleur | 1.07B 74% NTSC |
| Ligbron | No B/L |
| gewig | 2.60Kgs (Typ.) |
| ontwerp vir | TV Sets |
| raamkoers | 120Hz |
| raakpaneel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| HV550QUB-B10 | BOE | 55 | 3840×2160 |
| LC550DUN-SFU2 | LG Display | 55 | 1920×1080 |
| LC550DUY-SHA2 | LG Display | 55 | 1920×1080 |
| LC550EQE-PGF2 | LG Display | 55 | 3840×2160 |
| LC550WUB-SCA1 | LG Display | 55 | 1920×1080 |
| LD550DUN-THA3 | LG Display | 55 | 1920×1080 |
| LSC550FN05 | Samsung | 55 | 3840×2160 |
| LTA550HW03-002 | Samsung | 55 | 1920×1080 |
| P550HVN06.0 | AUO | 55 | 1920×1080 |
| T546HW01 V0 | AUO | 55 | 1920×1080 |
