| Onderdeel nommer | HV236WHB-N40 |
| Handelsmerk | BOE |
| Grootte | 23.6 |
| Toepassing | TV Sets |
| Resolusie | 1366×768 |
| Samestelling | CELL , a-Si TFT-LC |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| vervaardiger | BOE |
| skerm grootte | 23.6 inch |
| pixel nommer | 1366(RGB)×768 (WXGA) 66PPI |
| aktiewe area (mm) | 521.471 × 293.184 (H×V) |
| ring area (mm) | - |
| helderheid | 0 cd/m² |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| glas dikte | 0.50+0.50 mm |
| kleurdiepte | 16.7M 98% sRGB |
| massa | 471g (Typ.) |
| herlaaitempo | 60Hz |
| bestuurder ic lys | Built-in COF 2 source chips |
| sein tipe | LVDS (1 ch, 8-bit) , 30 pins Connector |
| spanningstoevoer | 12.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model naam | HV236WHB-N40 |
| tipe skerm | CELL , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 535.47 × 306.404 × 1.4 (H×V×D) |
| behandeling | Antiglare (Haze 1%) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| reaksie | 14 (Typ.)(G to G) ms |
| werksmodus | ADS, Normally Black, Transmissive |
| deurlaatbaarheid | 5.3% (Typ.)(with Polarizer) |
| agterlig | No B/L |
| gebruik vir | TV Sets |
| raakskerm | Without |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| HV236WHB-N00 | BOE | 23.6 | 1366×768 |
| M236H1-L01 | Innolux | 23.6 | 1920×1080 |
| M236H3-L05 | Innolux | 23.6 | 1920×1080 |
| M236H3-LA3 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJK-L3B | Innolux | 23.6 | 1920×1080 |
| M236MWF1 R0 | IVO | 23.6 | 1920×1080 |
| MV236WHM-N10 | BOE | 23.6 | 1366×768 |
| V236BJ1-P02 | Innolux | 23.6 | 1366×768 |
