| Onderdeel nommer | HT260WX2-101 |
| Handelsmerk | BOE |
| Grootte | 26.0 |
| Toepassing | LCTV |
| Resolusie | 1366×768 |
| Samestelling | CELL |
| Helderheid | 0 |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | No B/L |
| Koppelvlak | LVDS |
| paneel handelsmerk | BOE |
| paneel model | HT260WX2-101 |
| paneel tipe | a-Si TFT-LCD , CELL |
| paneel grootte | 26.0 inch |
| resolusie | 1366(RGB)×768 , WXGA |
| vertoonmodus | TN, Normally White, Transmissive |
| aktiewe area | 575.769×323.712 mm |
| buitelyn | 592×339.8 mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| glas diepte | 0.70+0.70 mm |
| deurlaatbaarheid | 7.05% (Typ.)(with Polarizer) |
| kontras verhouding | 800:1 (Typ.) |
| kleure vertoon | 16.7M (6-bit + Hi-FRC), CIE193172% |
| reaksie tyd | 5 (Typ.)(G to G) |
| kykhoek | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekwensie | 60Hz |
| sein koppelvlak | LVDS (1 ch, 8-bit), 30 pins |
| insetspanning | 12.0V (Typ.) |
| aansoek | LCTV |
