| Onderdeel nommer | HSD156JUW2-A10 |
| Handelsmerk | HannStar |
| Grootte | 15.6 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 1920×1080 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 4 |
| Koppelvlak | |
| vervaardiger | HannStar |
| skerm grootte | 15.6 inch |
| pixel nommer | 1920(RGB)×1080 (FHD) 141PPI |
| aktiewe area (mm) | 344.16 × 193.59 (H×V) |
| ring area (mm) | - |
| helderheid | 850 (Typ.)(cd/m²) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 70% |
| massa | TBD |
| herlaaitempo | 60Hz |
| model naam | HSD156JUW2-A10 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 363.7 × 215.7 (H×V×D) |
| behandeling | Hard coating |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| werksmodus | IPS Pro, Normally Black, Transmissive |
| reaksie | 15/15 (Max.)(Tr+Td) ms |
| agterlig | 4 strings WLED , 30K hours , No Driver |
| gebruik vir | Outdoor High Brightness Automotive Display |
| raakskerm | Without |
| AC156GA01 | Mitsubishi | 15.6 | 1366×768 |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LP156WF3-SLB3 | LG Display | 15.6 | 1920×1080 |
| LP156WH3-TLQ1 | LG Display | 15.6 | 1366×768 |
| LTN156AT01-A01 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-H01 | Samsung | 15.6 | 1366×768 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
| N156BGE-L62 | Innolux | 15.6 | 1366×768 |
