| Onderdeel nommer | HSD150GXN1-A00-C00 |
| Handelsmerk | HannStar |
| Grootte | 15.0 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 700:1 |
| Kleure | 262K/16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | HannStar |
| diagonale grootte | 15.0 inch |
| pixel formaat | 1024(RGB)×768 [XGA] 85PPI |
| aktiewe area | 304.128(H)×228.096(V) mm |
| ring area | 307.4(H)×231.3(V) mm |
| helderheid | 250 cd/m² (Typ.) |
| kyk rigting | - |
| kykhoek | 80/80/60/80 (Typ.)(CR≥10) |
| ondersteun kleur | 262K/16.2M 60% NTSC |
| gewig | 1.20Kgs (Max.) |
| raamkoers | 60Hz |
| koppelvlak tipe | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| model | HSD150GXN1-A00-C00 |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | 326.5(H)×253.5(V) ×12.7(D) mm |
| behandeling | - |
| kontras verhouding | 700:1 (Typ.) (TM) |
| reaksie tyd | 12 (Typ.)(Tr+Td) |
| bedryfsmodus | TN, Normally White, Transmissive |
| Ligbron | WLED , 30K hours , With LED Driver |
| ontwerp vir | Industrial |
| raakpaneel | Embeded Touch |
| G150XTN01.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| G150XVN01.0 | AUO | 15.0 | 1024×768 |
| HSD150PX16-A | HannStar | 15.0 | 1024×768 |
| LC150X01-A3K2 | LG Display | 15.0 | 1024×768 |
| LQ150X1LG92 | SHARP | 15.0 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL10276BC30-39 | NLT | 15.0 | 1024×768 |
| T150XG01 V2 | AUO | 15.0 | 1024×768 |
