| Onderdeel nommer | HSD123KPW2-D10 |
| Handelsmerk | HannStar |
| Grootte | 12.3 |
| Toepassing | Automotive Display |
| Resolusie | 1920×720 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1100:1 |
| Kleure | 16.7M |
| Agterlig | 11S4P |
| Koppelvlak | |
| vervaardiger | HannStar |
| model naam | HSD123KPW2-D10 |
| skerm grootte | 12.3 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×720 167PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 292.032 × 109.512 (H×V) |
| buitelyn (mm) | 308.1 × 130 × 15.6 (H×V×D) |
| ring area (mm) | 294.8 × 112.1 (H×V) |
| behandeling | Antiglare |
| helderheid | 850 cd/m² (Typ.) |
| kontras verhouding | 1100 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 14/16 (Max.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS Pro, Normally Black, Transmissive |
| kleurdiepte | 16.7M 100% sRGB |
| agterlig | 11S4P WLED , 30K hours , No Driver |
| massa | 515/540g (Typ./Max.) |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
