| Onderdeel nommer | HSD123KPW1-A30 |
| Handelsmerk | HannStar |
| Grootte | 12.3 |
| Toepassing | Automotive Display |
| Resolusie | 1920×720 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 11S4P |
| Koppelvlak | |
| paneel handelsmerk | HannStar |
| paneel grootte | 12.3" |
| resolusie | 1920(RGB)×720, 167PPI |
| vertoon area | 292.032(W)×109.512(H) mm |
| omtrek grootte | 308.1(W)×130(H) ×15.6(D) mm |
| helderheid | 850 cd/m² (Typ.) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 71% NTSC |
| frekwensie | 60Hz |
| gewig | 520g (Typ.) |
| paneel model | HSD123KPW1-A30 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 294.8(W)×112.1(H) mm |
| oppervlak | Antiglare |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | IPS Pro, Normally Black, Transmissive |
| reaksie tyd | 17/18 (Typ.)(Tr/Td) |
| tipe lamp | 11S4P WLED , 30K hours , Without Driver |
| raakskerm | Without |
| aansoek | Automotive Display |
