| Onderdeel nommer | HSD123JPW1-A20 |
| Handelsmerk | HannStar |
| Grootte | 12.3 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 1920×720 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 11S4P |
| Koppelvlak | LVDS |
| paneel handelsmerk | HannStar |
| paneel model | HSD123JPW1-A20 |
| paneel grootte | 12.3" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1920(RGB)×720, 167PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 292.032(W)×109.512(H) mm |
| ring opening | 294.8(W)×112.1(H) mm |
| omtrek grootte | 308.1(W)×130(H) ×16.6(D) mm |
| oppervlak | Antiglare |
| helderheid | 850 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| vertoonmodus | IPS Pro, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 18/17 (Typ.)(Tr/Td) |
| kleure vertoon | 16.7M 70% NTSC |
| tipe lamp | 11S4P WLED , 30K hours , Without Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 520g (Typ.) |
| aansoek | Outdoor High Brightness Automotive Display |
| sein koppelvlak | LVDS (2 ch, 8-bit) , 50 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
