| Onderdeel nommer | HSD121KXN1-A10-0299 |
| Handelsmerk | HannStar |
| Grootte | 12.1 |
| Toepassing | Automotive Display |
| Resolusie | 1024×768 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 900:1 |
| Kleure | 262K/16.7M |
| Agterlig | No |
| Koppelvlak | LVDS |
| vervaardiger | HannStar |
| model naam | HSD121KXN1-A10-0299 |
| skerm grootte | 12.1 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×768 (XGA) 105PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 245.76 × 184.32 (H×V) |
| buitelyn (mm) | 256.18 × 196.9 × 1.27 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS Pro, Normally Black, Transmissive |
| glas dikte | 0.50+0.50 mm |
| deurlaatbaarheid | - |
| kleurdiepte | 262K/16.7M 70% NTSC |
| agterlig | No B/L , No Driver |
| massa | 160/180g (Typ./Max.) |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
