| Onderdeel nommer | HSD103IPW1-A10-0299 |
| Handelsmerk | HannStar |
| Grootte | 10.3 |
| Toepassing | Automotive Display |
| Resolusie | 1280×480 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 900:1 |
| Kleure | 262K/16.7M |
| Agterlig | No |
| Koppelvlak | |
| vervaardiger | HannStar |
| model naam | HSD103IPW1-A10-0299 |
| skerm grootte | 10.3 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×480 (DVGA) 133PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 243.84 × 91.44 (H×V) |
| buitelyn (mm) | 253 × 103.3 × 1.25 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 900 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 30 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS Pro, Normally Black, Transmissive |
| glas dikte | 0.50+0.50 mm |
| deurlaatbaarheid | 4.7% (Typ.)(with Polarizer) |
| kleurdiepte | 262K/16.7M 70% NTSC |
| agterlig | No B/L |
| massa | TBD |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
