| Onderdeel nommer | HSD101PUW1-E00 |
| Handelsmerk | HannStar |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 1920×1200 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | MIPI |
| handelsmerk | HannStar |
| diagonale grootte | 10.1 inch |
| pixel formaat | 1920(RGB)×1200 [WUXGA] 225PPI |
| aktiewe area | 216.576(H)×135.36(V) mm |
| helderheid | - |
| kyk rigting | Symmetry |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| ondersteun kleur | 16.7M 50% NTSC |
| gewig | - |
| raamkoers | 60Hz |
| koppelvlak tipe | MIPI (4 data lanes) , 39 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | HSD101PUW1-E00 |
| tipe | a-Si TFT-LCD , LCM |
| konfigurasie | RGB Vertical Stripe |
| buitelyn dof. | - |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| bedryfsmodus | IPS Pro, Normally Black, Transmissive |
| Ligbron | WLED , 10K hours |
| ontwerp vir | Pad & Tablet |
| raakpaneel | Without |
| HSD101PFW2-B00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW3-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW4-B01 | HannStar | 10.1 | 1024×600 |
| HSD101PUW1-A00 | HannStar | 10.1 | 1920×1200 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A01 | HannStar | 10.1 | 1280×800 |
