| Onderdeel nommer | HSD101BFW6-A00 |
| Handelsmerk | HannStar |
| Grootte | 10.1 |
| Toepassing | Pad & Tablet |
| Resolusie | 1024×600 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| vervaardiger | HannStar |
| model naam | HSD101BFW6-A00 |
| skerm grootte | 10.1 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×600 (WSVGA) 117PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 222.72 × 125.28 (H×V) |
| buitelyn (mm) | 230.4 × 134.2 × 0.8 (H×V×D) |
| helderheid | 0 cd/m² |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 10/20 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS Pro, Normally Black, Transmissive |
| glas dikte | 0.40+0.40 mm |
| deurlaatbaarheid | 5.81% (Typ.)(with Polarizer) |
| kleurdiepte | 16.7M 45% NTSC |
| agterlig | No B/L |
| massa | - |
| gebruik vir | Pad & Tablet |
| herlaaitempo | - |
| raakskerm | Without |
| bestuurder ic lys | Suggest COG EK79007AD, HX8282-C, EK73215BCGA, HX8696-A |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| B101AW01 V2 HW0A | AUO | 10.1 | 1024×576 |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| B101UAN01.7 HW2A | AUO | 10.1 | 1920×1200 |
| BP101WX1-300 | BOE | 10.1 | 1280×800 |
| HSD100IFW1-A02 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LP101WX1-SLB1 | LG Display | 10.1 | 1280×800 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
| VVX10F004B00 | Panasonic | 10.1 | 1920×1200 |
