| Onderdeel nommer | HSD090JFW1-A02 |
| Handelsmerk | HannStar |
| Grootte | 9.0 |
| Toepassing | Automotive Display |
| Resolusie | 1024×600 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.2M |
| Agterlig | 3S13P |
| Koppelvlak | LVDS |
| vervaardiger | HannStar |
| model naam | HSD090JFW1-A02 |
| skerm grootte | 9.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1024(RGB)×600 (WSVGA) 132PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 196.608 × 114.15 (H×V) |
| buitelyn (mm) | 211.1 × 126.5 × 6 (H×V×D) |
| ring area (mm) | 200.01 × 117.55 (H×V) |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 500 cd/m² (Typ.) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 17/18 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS Pro, Normally Black, Transmissive |
| kleurdiepte | 16.2M 50% NTSC |
| agterlig | 3S13P WLED , 15K hours , No Driver |
| massa | 226g (Typ.) |
| gebruik vir | Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (1 ch, 8-bit) , FPC 40 pins |
| spanningstoevoer | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| maks. graderings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
