| Onderdeel nommer | HSD080JHW3-A11 |
| Handelsmerk | HannStar |
| Grootte | 8.0 |
| Toepassing | Outdoor High Brightn |
| Resolusie | 1280×720 |
| Samestelling | , a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleure | 262K/16.7M |
| Agterlig | WLED |
| Koppelvlak | |
| vervaardiger | HannStar |
| model naam | HSD080JHW3-A11 |
| skerm grootte | 8.0 inch |
| tipe skerm | , a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×720 (WXGA) 184PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 176.64 × 99.36 (H×V) |
| buitelyn (mm) | - |
| ring area (mm) | - |
| behandeling | Antireflection |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 800 : 1 (Typ.) (TM) |
| kykhoek | 85/85/85/85 (Typ.)(CR≥10) |
| reaksie | 17/18 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | IPS Pro, Normally Black, Transmissive |
| kleurdiepte | 262K/16.7M |
| agterlig | WLED , No Driver |
| massa | - |
| gebruik vir | Outdoor High Brightness Automotive Display |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
