| Onderdeel nommer | HSD070I651-D00-0299 |
| Handelsmerk | HannStar |
| Grootte | 7.0 |
| Toepassing | Digital Photo Frame |
| Resolusie | 480×234 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleure | Full |
| Agterlig | No |
| Koppelvlak | |
| vervaardiger | HannStar |
| model naam | HSD070I651-D00-0299 |
| skerm grootte | 7.0 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 480(RGB)×234 76PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 154.08 × 86.58 (H×V) |
| buitelyn (mm) | 164.9 × 100 × 1.69 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 0 cd/m² |
| kontras verhouding | 500 : 1 (Typ.) (TM) |
| kykhoek | 60/60/40/60 (Typ.)(CR≥10) |
| reaksie | 5/20 (Typ.)(Tr/Td) ms |
| goeie uitsig by | 6 o'clock |
| werksmodus | TN, Normally White, Transmissive |
| glas dikte | 0.63+0.63 mm |
| deurlaatbaarheid | 9.0% (Typ.)(with Polarizer) |
| kleurdiepte | Full color |
| agterlig | No B/L |
| massa | 55.3/58.3g (Typ./Max.) |
| gebruik vir | Digital Photo Frame Portable DVD Player |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
