| Onderdeel nommer | GV101WXB-NZ1-DGP0 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1280×800 |
| Samestelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | No |
| Koppelvlak | |
| vervaardiger | BOE |
| model naam | GV101WXB-NZ1-DGP0 |
| skerm grootte | 10.1 inch |
| tipe skerm | CELL, a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×800 (WXGA) 149PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 216.96 × 135.6 (H×V) |
| buitelyn (mm) | 221.96 × 144.43 × 1.06 (H×V×D) |
| ring area (mm) | - |
| behandeling | Without Polarizer, Hard coating |
| helderheid | 0 cd/m² |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 80/80/80/80 (Typ.)(CR≥10) |
| reaksie | 35 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | ADS, Normally Black, Transmissive |
| kleurdiepte | 16.7M 50% NTSC |
| agterlig | No B/L , With LED Driver |
| massa | - |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
