| Onderdeel nommer | GT101WSM-N10 |
| Handelsmerk | BOE |
| Grootte | 10.1 |
| Toepassing | Industrial |
| Resolusie | 1024×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K/16.7M |
| Agterlig | 4 |
| Koppelvlak | |
| paneel handelsmerk | BOE |
| paneel grootte | 10.1" |
| resolusie | 1024(RGB)×600, WSVGA, 117PPI |
| vertoon area | 222.72(W)×125.28(H) mm |
| omtrek grootte | 235(W)×143(H) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 70/70/0/60 (Typ.)(CR≥10) |
| beste uitsig op | - |
| kleure vertoon | 262K/16.7M 50% NTSC |
| frekwensie | 60Hz |
| gewig | 180g (Typ.) |
| paneel model | GT101WSM-N10 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 225.92(W)×128.48(H) mm |
| oppervlak | - |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 20 (Typ.)(Tr+Td) |
| tipe lamp | 4 strings WLED , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101AW03 V1 | AUO | 10.1 | 1024×600 |
| B101EAN01.6 | AUO | 10.1 | 1280×800 |
| B101XAN02.0 | AUO | 10.1 | 1366×768 |
| HJ101IA-01I | Innolux | 10.1 | 1280×800 |
| HSD101PFW2-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| HV101WU1-1E3 | HYDIS | 10.1 | 1920×1200 |
| M101NWT2 R3 | IVO | 10.1 | 1024×600 |
