| Onderdeel nommer | GT080S0M-N11-1QP0 |
| Handelsmerk | BOE |
| Grootte | 8.0 |
| Toepassing | Industrial |
| Resolusie | 800×600 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K/16.7M |
| Agterlig | 4S5P |
| Koppelvlak | |
| paneel handelsmerk | BOE |
| paneel grootte | 8.0" |
| resolusie | 800(RGB)×600, SVGA, 125PPI |
| vertoon area | 162(W)×121.5(H) mm |
| omtrek grootte | 183(W)×141(H) ×5.9(D) mm |
| helderheid | 250 cd/m² (Typ.) |
| kykhoek | 75/75/75/75 (Typ.)(CR≥10) |
| beste uitsig op | - |
| kleure vertoon | 262K/16.7M 50% NTSC |
| frekwensie | 60Hz |
| gewig | - |
| paneel model | GT080S0M-N11-1QP0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 164.8(W)×124.3(H) mm |
| oppervlak | Antiglare |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 20 (Typ.)(Tr+Td) |
| tipe lamp | 4S5P WLED , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
| A080SN03 V2 | AUO | 8.0 | 800×600 |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| B080UAN01.2 | AUO | 8.0 | 1200×1920 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| EJ080NA-04B | Innolux | 8.0 | 1024×768 |
| LD080UX1-SMA2 | LG Display | 8.0 | 1200×1600 |
| LQ080V3DG01 | SHARP | 8.0 | 640×480 |
| LQ080Y5DG02 | SHARP | 8.0 | 800×480 |
| LQ080Y5DW03 | SHARP | 8.0 | 800×480 |
| LSL080AL02-002 | Samsung | 8.0 | 800×1280 |
