| Onderdeel nommer | G270QAN02.0 |
| Handelsmerk | AUO |
| Grootte | 27.0 |
| Toepassing | Industrial |
| Resolusie | 2560×1440 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 4 |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| model naam | G270QAN02.0 |
| skerm grootte | 27.0 inch |
| tipe skerm | LCM , a-Si TFT-LCD |
| pixel nommer | 2560(RGB)×1440 (Quad-HD) 108PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 596.74 × 335.66 (H×V) |
| buitelyn (mm) | 606.44 × 355.56 × 15.03 (H×V×D) |
| ring area (mm) | - |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 350 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 8/8 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AHVA, Normally Black, Transmissive |
| kleurdiepte | 16.7M 99% sRGB |
| agterlig | 4 strings WLED , 30K hours , No Driver |
| massa | 3.50Kgs (Typ.) |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (4 ch, 8-bit) , 70 pins Connector |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 55 °C Operating Temp.: 0 ~ 50 °C |
