| Onderdeel nommer | G270QAN01.0 |
| Handelsmerk | AUO |
| Grootte | 27.0 |
| Toepassing | Industrial |
| Resolusie | 2560×1440 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 4 |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel grootte | 27.0" |
| resolusie | 2560(RGB)×1440, Quad-HD, 108PPI |
| vertoon area | 596.74(W)×335.66(H) mm |
| omtrek grootte | 630(W)×368.2(H) ×15.6(D) mm |
| helderheid | 350 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 100% Adobe RGB |
| frekwensie | 60Hz |
| paneel gewig | 3.15Kgs (Typ.) |
| sein koppelvlak | LVDS (4 ch, 8-bit) , 92 pins Connector |
| insetspanning | 5.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | G270QAN01.0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 601.6(W)×340.15(H) mm |
| oppervlak | Antiglare |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| reaksie tyd | 8/8 (Typ.)(Tr/Td) |
| tipe lamp | 4 strings WLED , 30K hours , Without Driver |
| raakskerm | Without |
| aansoek | Industrial |
| LM270WF5-SLM1 | LG Display | 27.0 | 1920×1080 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSB1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDA2 | LG Display | 27.0 | 2560×1440 |
| LM270WQ3-SLB2 | LG Display | 27.0 | 2560×1440 |
| M270DAN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.3 | AUO | 27.0 | 2560×1440 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| P270MWN1 R0 | IVO | 27.0 | 1920×1080 |
