| Onderdeel nommer | G270HAN01.2 |
| Handelsmerk | AUO |
| Grootte | 27.0 |
| Toepassing | Industrial |
| Resolusie | 1920×1080 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 22S4P |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| model naam | G270HAN01.2 |
| skerm grootte | 27.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1920(RGB)×1080 (FHD) 81PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 597.888 × 336.312 (H×V) |
| buitelyn (mm) | 611.48 × 355.81 × 13.3 (H×V×D) |
| ring area (mm) | 601.49 × 339.91 (H×V) |
| behandeling | Antiglare |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 14 (Typ.)(Tr+Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AHVA, Normally Black, Transmissive |
| kleurdiepte | 16.7M 72% NTSC |
| agterlig | 22S4P WLED , 50K hours , No Driver |
| massa | 2.87Kgs (Typ.) |
| gebruik vir | Industrial |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (2 ch, 8-bit) , Connector 30 pins |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
