| Onderdeel nommer | G270HAN01.0 |
| Handelsmerk | AUO |
| Grootte | 27.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 1.07B |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| paneel handelsmerk | AUO |
| paneel model | G270HAN01.0 |
| paneel grootte | 27.0" |
| paneel tipe | a-Si TFT-LCD, LCM |
| resolusie | 1920(RGB)×1080, FHD, 81PPI |
| pixel formaat | RGB Vertical Stripe |
| vertoon area | 597.888(W)×336.312(H) mm |
| ring opening | 602(W)×340.4(H) mm |
| omtrek grootte | 630(W)×368.2(H) ×23.4(D) mm |
| oppervlak | Antiglare |
| helderheid | 1000 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| beste uitsig op | Symmetry |
| reaksie tyd | 14 (Typ.)(Tr+Td) |
| kleure vertoon | 1.07B 87% NTSC |
| tipe lamp | WLED , 50K hours , With LED Driver |
| frekwensie | 60Hz |
| raakskerm | Without |
| paneel gewig | 3.40Kgs (Typ.) |
| aansoek | Industrial Outdoor High Brightness |
| sein koppelvlak | LVDS , 51 pins Connector |
| insetspanning | 12.0V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
