| Onderdeel nommer | G190EAN01.3 |
| Handelsmerk | AUO |
| Grootte | 19.0 |
| Toepassing | Industrial Medical I |
| Resolusie | 1280×1024 |
| Samestelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| model naam | G190EAN01.3 |
| skerm grootte | 19.0 inch |
| tipe skerm | LCM, a-Si TFT-LCD |
| pixel nommer | 1280(RGB)×1024 (SXGA) 86PPI |
| reëling | RGB Vertical Stripe |
| aktiewe area (mm) | 376.32 × 301.056 (H×V) |
| buitelyn (mm) | 396 × 324 × 15.8 (H×V×D) |
| ring area (mm) | 380.32 × 305.06 (H×V) |
| behandeling | Antiglare |
| helderheid | 330 cd/m² (Typ.) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| reaksie | 13/12 (Typ.)(Tr/Td) ms |
| goeie uitsig by | Symmetry |
| werksmodus | AHVA, Normally Black, Transmissive |
| kleurdiepte | 16.7M 72% NTSC |
| agterlig | WLED , 50K hours , With LED Driver |
| massa | 1.70±0.15Kgs |
| gebruik vir | Industrial Medical Imaging |
| herlaaitempo | 60Hz |
| raakskerm | Without |
| sein tipe | LVDS (2 ch, 8-bit) , Connector 30 pins |
| spanningstoevoer | 5.0V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| G190EAN01.0 | AUO | 19.0 | 1280×1024 |
| G190EG01 V0 | AUO | 19.0 | 1280×1024 |
| G190EG01 V1 | AUO | 19.0 | 1280×1024 |
| G190EG01 V2 | AUO | 19.0 | 1280×1024 |
| G190EG02 V0 | AUO | 19.0 | 1280×1024 |
| G190EG02 V1 | AUO | 19.0 | 1280×1024 |
| G190ETN01.0 | AUO | 19.0 | 1280×1024 |
| G190ETN01.2 | AUO | 19.0 | 1280×1024 |
| G190ETN01.4 | AUO | 19.0 | 1280×1024 |
| G190ETN02.0 | AUO | 19.0 | 1280×1024 |
