| Onderdeel nommer | G170HAN01.0 |
| Handelsmerk | AUO |
| Grootte | 17.0 |
| Toepassing | Industrial |
| Resolusie | 1920×1920 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | 9S6P |
| Koppelvlak | |
| paneel handelsmerk | AUO |
| paneel grootte | 17.0" |
| resolusie | 1920(RGB)×1920, 159PPI |
| vertoon area | 305.28(W)×305.28(H) mm |
| omtrek grootte | 325.01(W)×319.33(H) ×12.2(D) mm |
| helderheid | 600 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.7M 72% NTSC |
| frekwensie | 60Hz |
| gewig | 1.20Kgs (Max.) |
| paneel model | G170HAN01.0 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| vertoonmodus | AHVA, Normally Black, Transmissive |
| reaksie tyd | 13/12 (Typ.)(Tr/Td) |
| tipe lamp | 9S6P WLED , 50K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
