| Onderdeel nommer | G170ETN03.1 |
| Handelsmerk | AUO |
| Grootte | 17.0 |
| Toepassing | Industrial |
| Resolusie | 1280×1024 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | AUO |
| model | G170ETN03.1 |
| diagonale grootte | 17.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1280(RGB)×1024 [SXGA] 96PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 337.92(H)×270.336(V) mm |
| buitelyn dof. | 358.5(H)×296.5(V) ×10.8(D) mm |
| ring area | 341.7(H)×274.1(V) mm |
| behandeling | Antiglare, Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| kontras verhouding | 1000:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 3.8/1.2 (Typ.)(Tr/Td) |
| kykhoek | 85/85/80/80 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 16.7M 72% NTSC |
| Ligbron | WLED [9S4P] , 30K hours , W/O Driver |
| gewig | 1.27Kgs (Typ.) |
| ontwerp vir | Industrial |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| kragtoevoer | 5.0V (Typ.) |
| omgewing | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
