| Onderdeel nommer | G156XTN02.0 |
| Handelsmerk | AUO |
| Grootte | 15.6 |
| Toepassing | Industrial |
| Resolusie | 1366×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 400:1 |
| Kleure | 262K |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | AUO |
| paneel grootte | 15.6" |
| resolusie | 1366(RGB)×768, WXGA, 100PPI |
| vertoon area | 344.232(W)×193.536(H) mm |
| omtrek grootte | 359.5(W)×223.8(H) ×3.2(D) mm |
| helderheid | 220 cd/m² (Typ.) |
| kykhoek | 45/45/15/35 (Typ.)(CR≥10) |
| beste uitsig op | 6 o'clock |
| kleure vertoon | 262K 45% NTSC |
| frekwensie | 60Hz |
| paneel gewig | 380g (Max.) |
| sein koppelvlak | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | G156XTN02.0 (AUO71EC) |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 400:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 8 (Typ.)(Tr+Td) |
| tipe lamp | WLED , 15K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
