| Onderdeel nommer | G156HAN02.1 |
| Handelsmerk | AUO |
| Grootte | 15.6 |
| Toepassing | Industrial Medical I |
| Resolusie | 1920×1080 |
| Samestelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleure | 16.7M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| vervaardiger | AUO |
| skerm grootte | 15.6 inch |
| pixel nommer | 1920(RGB)×1080 (FHD) 141PPI |
| aktiewe area (mm) | 344.16 × 193.59 (H×V) |
| ring area (mm) | 347.06 × 196.49 (H×V) |
| helderheid | 500 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| goeie uitsig by | Symmetry |
| kleurdiepte | 16.7M 99% sRGB |
| massa | 600/660g (Typ./Max.) |
| herlaaitempo | 60Hz |
| sein tipe | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningstoevoer | 3.3V (Typ.) |
| maks. graderings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
| model naam | G156HAN02.1 |
| tipe skerm | LCM , a-Si TFT-LCD |
| reëling | RGB Vertical Stripe |
| buitelyn (mm) | 363.8 × 215.9 × 9.3 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| kontras verhouding | 1000 : 1 (Typ.) (TM) |
| reaksie | 25 (Typ.)(Tr+Td) ms |
| werksmodus | AHVA, Normally Black, Transmissive |
| agterlig | WLED , 50K hours , With LED Driver |
| gebruik vir | Industrial Medical Imaging |
| raakskerm | Without |
