| Onderdeel nommer | G156HAB01.0 |
| Handelsmerk | AUO |
| Grootte | 15.6 |
| Toepassing | Industrial |
| Resolusie | 1920×1080 |
| Samestelling | a-Si TFT-LCD , Assem |
| Helderheid | |
| CR | 800:1 |
| Kleure | 16.2M |
| Agterlig | WLED |
| Koppelvlak | eDP |
| paneel handelsmerk | AUO |
| paneel grootte | 15.6" |
| resolusie | 1920(RGB)×1080, FHD, 141PPI |
| vertoon area | 344.16(W)×193.59(H) mm |
| omtrek grootte | 361(W)×227(H) ×4.9(D) mm |
| helderheid | 300 cd/m² (Typ.) |
| kykhoek | 89/89/89/89 (Typ.)(CR≥10) |
| beste uitsig op | Symmetry |
| kleure vertoon | 16.2M 45% NTSC |
| frekwensie | 60Hz |
| paneel gewig | 620g (Max.) |
| sein koppelvlak | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| insetspanning | 3.3V (Typ.) |
| omgewing | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneel model | G156HAB01.0 |
| paneel tipe | a-Si TFT-LCD , Assembly |
| pixel formaat | RGB Vertical Stripe |
| ring opening | - |
| oppervlak | Hard coating (7H) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| vertoonmodus | - |
| reaksie tyd | 25 (Typ.)(Tr+Td) |
| tipe lamp | WLED , 30K hours , With LED Driver |
| raakskerm | On-Cell Touch |
| aansoek | Industrial |
