| Onderdeel nommer | G150XTN06.9 |
| Handelsmerk | AUO |
| Grootte | 15.0 |
| Toepassing | Industrial Outdoor H |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleure | 262K/16.2M |
| Agterlig | WLED |
| Koppelvlak | LVDS |
| handelsmerk | AUO |
| model | G150XTN06.9 |
| diagonale grootte | 15.0 inch |
| tipe | a-Si TFT-LCD, LCM |
| pixel formaat | 1024(RGB)×768 [XGA] 85PPI |
| konfigurasie | RGB Vertical Stripe |
| aktiewe area | 304.128(H)×228.096(V) mm |
| buitelyn dof. | 326.5(H)×253.5(V) ×10(D) mm |
| ring area | 311.9(H)×236.85(V) mm |
| behandeling | Antiglare |
| helderheid | 1600 cd/m² (Typ.) |
| kontras verhouding | 800:1 (Typ.) (TM) |
| kyk rigting | - |
| reaksie tyd | 5.7/2.3 (Typ.)(Tr/Td) |
| kykhoek | 80/80/70/80 (Typ.)(CR≥10) |
| bedryfsmodus | TN, Normally White, Transmissive |
| ondersteun kleur | 262K/16.2M 60% NTSC |
| Ligbron | WLED , 50K hours , With LED Driver |
| gewig | 1.00Kgs (Max.) |
| ontwerp vir | Industrial Outdoor High Brightness |
| raamkoers | 60Hz |
| raakpaneel | Without |
| koppelvlak tipe | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| kragtoevoer | 3.3V (Typ.) |
| omgewing | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 70 °C |
| G150XG01 V0 | AUO | 15.0 | 1024×768 |
| G150XG01 V1 | AUO | 15.0 | 1024×768 |
| G150XG01 V2 | AUO | 15.0 | 1024×768 |
| G150XG03 V2 | AUO | 15.0 | 1024×768 |
| G150XG03 V3 | AUO | 15.0 | 1024×768 |
| G150XG03 V5 | AUO | 15.0 | 1024×768 |
| G150XGE-L04 Rev.C4 | Innolux | 15.0 | 1024×768 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.2 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
