| Onderdeel nommer | G150XTN03.7 |
| Handelsmerk | AUO |
| Grootte | 15.0 |
| Toepassing | Industrial |
| Resolusie | 1024×768 |
| Samestelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleure | 262K/16.2M |
| Agterlig | WLED |
| Koppelvlak | |
| paneel handelsmerk | AUO |
| paneel grootte | 15.0" |
| resolusie | 1024(RGB)×768, XGA, 85PPI |
| vertoon area | 304.128(W)×228.096(H) mm |
| omtrek grootte | 326.5(W)×253.5(H) ×10(D) mm |
| helderheid | 250 cd/m² (Typ.) |
| kykhoek | 45/45/20/40 (Typ.)(CR≥10) |
| beste uitsig op | - |
| kleure vertoon | 262K/16.2M 60% NTSC |
| frekwensie | 60Hz |
| gewig | 1.02Kgs (Max.) |
| paneel model | G150XTN03.7 |
| paneel tipe | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| ring opening | 313.55(W)×237.25(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| kontras verhouding | 500:1 (Typ.) (TM) |
| vertoonmodus | TN, Normally White, Transmissive |
| reaksie tyd | 6/2 (Typ.)(Tr/Td) |
| tipe lamp | WLED , 50K hours , With LED Driver |
| raakskerm | Without |
| aansoek | Industrial |
